VIVITEK 85-in 4K Display, 24/7, Portrait, Landscape, Digital Signage
DK854
NovoDisplay DK Series
Digital Signage Display with Collaboration Functionality
The NovoDisplay DK offers 4K Ultra-HD (3,840 x 2,160) resolution. With the included NovoDS Digital Signage software you will create, publish and manage content ranging from promotional announcements to company messages. With the added NovoConnect Wireless Collaboration solution, the NovoDsiplay can easily be switched to presentation mode. The NovoDisplay DK is suitable for commercial applications such as hospitality, retail, education and business.
Key Features
• 4K-UHD Display for outstanding details and stunning visuals
• Backlit D-LED (IPS panel) technology that offers flawless colour
• 500 cd/m2 brightness and 50,00 hours of operation for a professional signage display
• High Haze Value for an Exceptional Viewing Experience
• Extra wide viewing angle (178°/178°)
• Supports Portrait and Landscape installation
Specifications
Panel Size: 85"
Type/Technology: Backlit D-LED (IPS-ADS)
Brightness: 500 cd/m²
Native Resolution: 4K-UHD
Viewing Angle (H/V): 178° / 178°
Refresh Rate: 60 Hz
Estimated Life Time: 50,000 hours
Display Color (Bit): 1.07 Billion
Installation Orientation: Portrait & Landscape
Daily Operation (Hours/Days): 16/7
Bezel Size: Bezel Even
Internal Storage: 32GB (eMMC Flash)
External USB: Yes (FAT32 / NTFS)
Contrast Ratio: 4,000:1
I/O Connection Ports: HDMI-In (x2), HDMI-Out (x1), HDMI Version (2), Audio-In (3.5mm) x1, Audio-Out (3.5mm) x1, LAN (RJ45 x1), WiFi (WiFi 6; 802.11 a/b/g/n/ac/ax (2.4GHz/6GHz) USB dongle), RS-232 (RJ45) (1x), RS232-In (1x), USB A (v3.0 x1, v2.0 x1), microSD (1x), IR Receiver (1x)
Available Colors: Black
Dimensions (W x D x H): 1,915.6 × 1,096.8 × 100.7 mm
VESA Mounting (FPMPMI): 4 – M8 × 16mm, 500 × 500 mm
Power: AC 100–240V, 50/60Hz ≤300W, <0.5W (Standby)
Standard Accessories: HDMI Cable, Warranty Card (by region), Remote Controller (with battery), WiFi 6 USB Module (1x), AC Power Cord, Wall Mount Kit, Documentation Kit
Optional Accessories: LauncherPlus (Optional), LauncherOne (Optional), VIVOTEK Camera (Optional), Wall Mount Kit
Warranty: Flat Panel Standard Warranty: 3 Years (panel only, accessories excluded i.e. OPS); Flat Panel Education Warranty: 5 Years (registration required, panel only, accessories excluded i.e. OPS)
